JGFK71-6Z/5.5
Scope of application: mainly used for wood door cutting machine, wood slotting machine, floor slotting machine, wood slotting, cutting, etc. Product advantages: 1. The product has the characteristics of low speed, high torque and high precision. 2. It adopts professional fan design, with lower noise. 3. It adopts high rigid bearing, with stronger bearing capacity. 4. It can be equipped with imported bearing, with longer service life
key word:
JGFK71-6Z/5.5
Product Description
performance parameter
| Spindle model | JGFK71-6Z/5.5 | |
| Motor parameters | Rated power (KW) | 5.5 |
| Voltage | 380/220V | |
| Current | 12.2/21.2 | |
| Frequency (Hz) | 100 | |
| Speed (r/min) | 6000 | |
| Torque (NM) | 8.8 | |
| Shaft end connection | Ф 30 chuck - M30 * 2 left (right) | |
| Lubrication method | Grease | |
| Number of bearings | 4 | |
| Weight (Kg) | 28.5 | |
Outline drawing
以上产品具有代表性的规格，如有更改不另行通知。可按客户要求定制，如有疑问，请联系电话0519-83997719，手机：15061137201
